Programming in SQL can be both a fun and a challenging task. Those with a background in traditional programming languages such as Java, C, C++, and VB often find it difficult to adapt to the “set-based” mindset. Even seasoned SQL developers and DBAs can get trapped in one of the many pitfalls of the SQL language. I have been there and I’m willing to bet that you have too. Mastering the fundamentals takes time, and even then some mistakes are hard to spot.

My intention with this article was to highlight some of the more common mistakes that I’ve seen people make when coding SQL. The list reflects my direct experience working with different development teams and developers, performing code review sessions, and so on, as well as the issues I see every day on the newsgroups and forums. The list of common mistakes is far from exhaustive, and is presented in no particular order of severity. In fact, the list could be regarded as the result of the following query:

Without further ado, here is the list:

  1. NULLs and the NOT IN predicate
  2. Functions on indexed columns in predicates
  3. Incorrect subquery column
  4. Data type mismatch in predicates
  5. Predicate evaluation order
  6. Outer joins and placement of predicates
  7. Subqueries that return more than one value
  8. Use of SELECT *
  9. Scalar user-defined functions
  10. Overuse of cursors

The examples are presented using SQL Server’s Transact-SQL dialect, but most of the concepts are valid in any SQL implementation.

NULLs and the NOT IN predicate

One of the most common requests is to retrieve data based on some column value not included in a list of values. The following two tables illustrate the scenario. We have tables with colors and products:

Colors table:

Note that these tables do not represent a perfect design, following normalization rules and best practices. Rather, it is a simplified scenario to help illustrate this example better. In reality, the colors table would most likely contain a color code key column that would be referenced in the products table.

The request is to select a list of colors that have not previously been used on products. In other words, we need to construct a query that returns only those colors for which there is no product with that color. It might seem, at first glance, that the NOT IN predicate provides a very intuitive way to satisfy this request, very close to how the problem would be stated in plain English:

You may have been expecting this query to return two rows (for ‘black’ and ‘green’) but, in fact, it returns an empty result set:

Obviously this is ‘incorrect’. What is the problem? It’s simply that SQL uses three-valued logic, driven by the existence of NULL, which is not a value but a marker to indicate missing (or UNKNOWN) information. When the NOT operator is applied to the list of values from the subquery, in the IN predicate, it is translated like this:

This is equivalent to:

The expression “color=NULL” evaluates to UNKNOWN and, according to the rules of three-valued logic, NOT UNKNOWN also evaluates to UNKNOWN. As a result, all rows are filtered out and the query returns an empty set.

This mistake will often surface if requirements change, and a non-nullable column is altered to allow NULLs. It also highlights the need for thorough testing. Even if, in the initial design, a column disallows NULLs, you should make sure your queries continue to work correctly with NULLs.

One solution is to use the EXISTS predicate in place of IN, since EXISTS uses two-valued predicate logic evaluating to TRUE/FALSE:

This query correctly returns the expected result set:

Other possible solutions are as follows:

While all solutions produce the desired results, using EXCEPT may be the easiest to understand and use. Note that the EXCEPT operator returns distinct values, which works fine in our scenario but may not be correct in another situation.

Functions on indexed columns in predicates

We often tend to write code as a direct translation of given request. For example, if we are asked to retrieve all customers whose name starts with the letter L, it feels very natural to write the query like this, using the LEFT function to return the first character of their name:

Alternatively, if we are asked to calculate the total sales for January 2009, we might write a query like the following, which uses the DATEPART function to extract the relevant month and year from the sale_date column:

While these queries look very intuitive, you will find that the indexes that you (of course!) have on your customer_name and sale_date columns remain unused, and that the execution plan for these queries reveal index scans.

The problem arises from the fact that the index columns are being passed to a function, which the query engine must then evaluate for every single row in the table. In cases such as these, the WHERE clause predicate is deemed “non-SARGable” and the best that the query optimizer can do is perform a full index or table scan.

To make sure the indexes get used, we need to avoid the use of functions on the indexed columns. In our two examples, it is a relatively simple task to rewrite the queries to use SARG-able predicates. The first requested can be expressed with this logically equivalent query:

The equivalent for the second query is as follows:

These two queries are most likely to utilize index seek to retrieve the data quickly and efficiently.

It’s worth noting that SQL Server is getting “smarter” as it evolves. For example, consider the following query, which uses the CAST function on the indexed sale_date column:

If you run this query on SQL 2005 or earlier, you’ll see an index scan. However, on SQL Server 2008 you’ll see an index seek, despite the use of the CAST function. The execution plan reveals that the predicate is transformed into something like the following:

However, in general, you should use SARGable predicates where possible, rather than rely on the evolving intelligence of the optimizer.

Incorrect subquery column

When writing a subquery, it is very easy to abstract yourself from the main query logic and concentrate on the subquery itself. This can lead to the innocent mistake of substituting a column from the subquery source table for a column with similar name from the main query.

Let’s look at two very simple tables; one is a Sales table containing sales data, and the other is an auxiliary Calendar table that has all calendar dates and holidays (abbreviated here):

Sales table:

Calendar table:

Our task is to retrieve sales data for holiday dates only. It seems like a trivial query to write:

However, you’ll find that query simply returns all rows from the Sales table! A closer look at the query reveals that the culprit to be the SELECT list of the subquery. It accidentally references the sales_date column from the Sales table, instead of the calendar_date column from the Calendar table.

If that is the case, why did we not get an error? Although the outcome was not what we expected, this is still a valid SQL statement. When using a subquery, the outer query’s columns are exposed to the inner query. Here, we unintentionally converted the self-contained subquery, to be executed once and the value passed to the outer query, to a correlated subquery, logically executed once for every row returned by the outer query.

As a result, the subquery evaluates to sale_date IN (sale_date) which is always true, as long as there is at least one holiday date in the Calendar table, and so our result set returns all rows from the Sales table. Of course, the fix is easy in this case; we simply use the correct date column from the Calendar table:

This illustrates another important point: it is a best practice to prefix columns in subqueries with table aliases. For example, if we had used an alias like this:

Then this query would have resulted in an error – “Error: Invalid column name ‘sale_date'”.

Data type mismatch in predicates

This is another typical mistake that is sometimes hard to catch. It is very easy to mismatch data types in predicates. It could be in a stored procedure where the parameter is passed as one data type and then used in a query to filter data on a column of different data type. Another example is joining tables on columns with different data types, or simply using a predicate where data types are mismatched.

For example, we may have a Customers table where the last_name column is of type VARCHAR:

Then the following stored procedure is used to retrieve the customer information by customer last name:

Notice here the parameter @last_name is of data type NVARCHAR. Although the code “works”, SQL Server will have to perform implicit conversion of the last name column to NVARCHAR, because NVARCHAR is of higher data precedence. This can result in a performance penalty. The implicit conversion is visible in the query plan as CONVERT_IMPLICIT. Based on collation, and other factors, a data type mismatch may also preclude the use of an index seek. Use of the correct data type resolves the problem:

In many cases, this mistake is the result of splitting responsibilities on the team, and having one team member design the tables and another implement stored procedures or code. Another reason could be using different data sources to join data where the join columns have different data types in the source systems. The same advice applies not only to character data type mismatches, but also to mismatches between numeric data types (like INT and FLOAT), or the mixing of numeric and character data types.

Predicate evaluation order

If you are familiar with the logical query processing order, then you may expect that a query is executed in the following order:

  1. FROM
  2. WHERE
  3. GROUP BY
  4. HAVING
  5. SELECT

The sequence above outlines the logical order for executing query. Logically the FROM clause is processed first defining the source data set, next the WHERE predicates are applied, followed by GROUP BY, and so on.

However, physically, the query is processed differently and the query optimizer is free to move expressions in the query plan in order to produce the most cost efficient plan for retrieving the data. This leads to a common misunderstanding that a filter in the WHERE clause is applied before the next phases are processed. In fact, a predicate can be applied much later in the physical execution plan. Also, there is no left to right order for execution of predicates. For example, if you have a WHERE clause containing “WHERE x=1 AND y=2“, there is no guarantee that “x=1” will be evaluated first. They can be executed in any order.

For example, consider the following Accounts table where, in the account_reference column, Business accounts are denoted by a numeric reference and Personal accounts by a character reference:

In general, this table indicates bad design. The account_reference column should be represented as two different attributes, specific to business and personal accounts and each with the correct data type (not even belonging to the same table). However, in practice, we very often have to deal with systems designed with shortcomings, where altering the design is not an option.

Given the above scenario, a valid request is to retrieve all business type accounts with an account reference that is greater than 20 (assuming account reference has some meaningful numeric value for business type accounts). The query may look like this:

However, the query results in error:

The query fails because, as noted earlier, there is no prescribed order for executing predicates and nothing guarantees that the predicate “account_type LIKE ‘Business%’” will be evaluated before the predicate “CAST(account_reference AS INT) > 20“. In our case, the second predicate is evaluated first resulting in a conversion error, due to the incompatible values in the account_reference column, for personal accounts.

One attempt to resolve this issue might be to use a derived table (or common table expression) to filter the business type accounts first, and then apply the predicate for account_reference column:

However, this results in the exact same error because derived tables and CTEs are expanded in the query plan and a single query plan is produced, where predicates can again be pushed up or down in the plan.

As indicated earlier, the problem here is a mix of bad design and misunderstanding of how SQL Server performs physical query execution. What is the solution? The best solution is to design the table correctly and avoid storing mixed data in a single column. In this case, a work around is to use a CASE expression to guarantee that only valid numeric values will be converted to INT data type:

The CASE expression uses a LIKE pattern to check for valid numeric values (a double negation logic is used which can be translated as “there is not a single character that is not a digit”), and only for those values performs the CAST. For the rest of the values the CASE expression results in NULL, which is filtered out because NULL is not matched with any value (even with NULL).

Outer joins and placement of predicates

Outer joins are such a great tool but are also much misunderstood and abused. Some people seem to like them so much that they throw one into almost every query, regardless of whether or not it is needed!

The key to correct use of outer joins is an understanding of the logical steps required to process an outer join in a query. Here are the relevant steps from the query processing phases:

  1. A cross join (Cartesian product) is formed for the two input tables in the FROM clause. The result of the Cartesian product is every possible combination of a row from the first table and a row from the second table.
  2. The ON clause predicates are applied filtering only rows satisfying the predicate logic.
  3. Any Outer rows filtered out by the predicates in step 2 are added back. Rows from the preserved table are added with their actual attribute values (column values), and the attributes (columns) from the non preserved table are set to NULL.
  4. The WHERE clause predicates are applied.

An outer join query can produce completely different results depending on how you write it, and where predicates are placed in that query. Let’s look at one example, based on the following two tables, Customers and Orders:

Customers table:

Orders table:

Our task is to retrieve a list of all customers, and the total amount they have spent on orders, since the beginning of year 2009. Instinctively, one may write the following query:

But the results do not look good:

Customers Jeff and Julie are missing from the result set. Where is the problem? In order to understand what went wrong, let’s play back this query one step at a time following the logical processing order. The first step is a cross join between the two input tables:

This results in every possible combination of rows from both input tables:

The next step is applying the ON predicates of the JOIN clause:

The result of this query includes only customers with orders. Since customer Julie does not have any orders it is excluded from the result set:

The third step of the logical processing order is adding back the outer rows. These rows were excluded in the prior step because they did not satisfy the join predicates.

Now customer Julie is added back in the result set. Notice the added outer rows from the preserved table (Customers) have values for the selected attributes (customer_name) and the non-preserved table (Orders) rows have NULL for their attributes (order_amt and order_date):

The last step is applying the WHERE clause predicates:

Now the picture is clear! The culprit is the WHERE clause predicate. Customer Jeff is filtered out from the result set because he does not have orders past January 1, 2009, and customer Julie is filtered out because she has no orders at all (since the outer row added for Julie has NULL for the order_date column). In effect, in this case, the predicate in the WHERE clause turns the outer join into an inner join.

To correct our initial query, it is sufficient to move the WHERE predicate into the join condition.

Now, the query returns correct results because Jeff and Julie are filtered out in the join predicates, but then added back when the outer rows are added.

In a more complex example, with multiple joins, the incorrect filtering may happen on a subsequent table operator (like join to another table) instead in the WHERE clause. For example, say we have an OrderDetails table containing product SKU and quantity, and the request is to retrieve a list of all customers, with order amount and quantity, for selected product SKUs. The following query may seem correct:

However, here the INNER join with the OrderDetails table plays the exact same role as the predicate in the WHERE clause in our previous example, in effect turning the LEFT OUTER join to INNER join. The correct query to satisfy this request needs to use a LEFT OUTER join to join to the OrderDetails table:

Subqueries that return more than one value

A very frequent request is to retrieve a value based on some correlation with the main query table. For example, consider the following two tables, storing details of products and the plants that manufacture these products:

Products table:

ProductPlants table:

The request is to extract the manufacturing plant for each product. One way to satisfy the request is to write the following query using correlated subquery to retrieve the plant:

Note that the point here is to illustrate a technique; there could be a more efficient way to accomplish the same task. However, all works fine and we get the correct result set:

The query will continue to work happily until the day arrives that the company decides to start manufacturing Balls at plant 3, to cope with increasing demand. The ProductPlants table now looks like this:

All of a sudden, our query starts generating the following error:

The error is descriptive enough. Instead of the expected scalar value, our subquery returns a result set, which breaks the query. Based on our business requirements, the fix is simple. To list all plants manufacturing plant for a particular product, we simply use a JOIN:

Now the query completes without errors and returns the correct results:

Note that the same error can occur in a predicate where a column or expression is tested against a subquery, for example “… column = (SELECT value FROM Table)“. In that case, the solution is to use the IN predicate in place of “=”.

Use of SELECT *

On first encounter with SQL we always praise the genius who invented the syntax SELECT *! It’s so handy and easy to use! Instead of explicitly listing all column names in our query, we just use the magic wildchar ‘*’ and retrieve all columns. For example, a common misuse of SELECT * is to extract a set of all plastic products and to insert them into another table with the same structure:

Job done! However, one day business requirements change and two new columns are added to the Products table:

All of sudden the magic query results in error:

The fix is to explicitly list the column names in the query:

The situation can get even worse if a view is created using SELECT *, and later the base tables are modified to add or drop columns.

Note: If a view is create using the SCHEMABINDING option, then the base tables cannot be modified in a way that will affect the view definition.

To conclude, do not use SELECT * in production code! One exception here is when using the EXISTS predicate. The select list in the subquery for the EXISTS predicate is ignored since only the existence of rows is important.

Scalar user-defined functions

Reuse of code is one of the fundamental principles we learn when programming in any language, and the SQL language is no exception. It provides many means by which to logically group code and reuse it.

One such means in SQL Server is the scalar user-defined function. It seems so convenient to hide away all those complex calculations in a function, and then simply invoke it in our queries. However, the hidden “sting in the tail” is that it can bring a heavy toll in terms of performance. When used in a query, scalar functions are evaluated for each row and, with large tables, this can result in very slow running queries. This is especially true when the scalar function needs to access another table to retrieve data.

Here is one example. Given tables with products and sales for products, the request is to retrieve total sales per product. Since the total sales value can be reused in another place, you decide to use a scalar function to calculate the total sales for a product:

Then the query to retrieve the total sales for each product will look like this;

Isn’t this a very neat and good looking query? But just wait until you run it over a large data set. The total sales calculation will be repeated for each and every row, and the overhead will be proportional to the number of rows. The correct way to handle this is, if possible, is to rewrite the function as a table-valued function, or simply perform the calculation in the main query. In our example, performing the calculation in the query will look like this:

And here is a table-valued function that can be used to calculate total sales:

Now the table-valued function can be invoked in the query using the APPLY operator:

Overuse of cursors

Let’s face it – we love loops! Whether we start programming with VB, C, C++, Java, or C#, one of the first constructs we encounter is some form of a loop. They can helpfully solve pretty much any challenge you might face.

And so, it is only natural on the day we start programming with SQL to seek out our favorite loop construct. And here it is – the mighty cursor (and its little WHILE brother)! Then we hurry to put the well known tool to use in solving our problems.

Let’s look at one example. Given a table with product prices, we have to perform a monthly update of prices for products; the price updates are stored in another table with new prices.

ProductPrices table:

NewPrices table:

A cursor solution may look like this:

Mission accomplished! Now we can take a well-deserved break while the query is running. Soon, the realization dawns that procedural row by row processing is not working well in SQL. Besides being very slow, our solution is long, hard to read and maintain. This is the moment we understand the power of SQL is its set-based nature. The same task can be accomplished using a very efficient set-based query that is easier to understand and maintain:

There are different ways to write a set based query to solve this problem: using the MERGE statement, update with Common Table Expression, or the SQL Server specific update with join. But the point is to utilize the natural power of the SQL language and use set based techniques to solve problems and to avoid procedural solutions.

Note: While you should avoid cursors as much as possible, there are certain problems, such as running total aggregations, that today are still best solved using cursors. We can be optimistic that future enhancements will provide better tools to solve those problems in a set based way.

Summary

Maybe now is a good time for the next code review of your SQL code. Hopefully some of these examples will help you be a better developer/DBA and produce more reliable and efficient code. It is not always easy to spot these patterns, especially in more complex queries. But as long as you understand the fundamentals, avoiding these mistakes is easy.

Happy SQL coding!
